Wieland Cable Cooupling for 10 x 16 Amp

Heavy duty cable connector pair male / female for 10 cables.

• Top and bottom housing made of cast aluminum
• Contacts rated for 16 Amp, 750 VAC
• Movable housing: Wieland 77.350.1028.0
• Insert Wieland type 72.300.1053
• Cable infeed on movable side: from the short side of the housing
• Fixed side housing: Wieland part number 77.320.1028.0
• Fixed side insert: Wieland part 72.310.1053
• Cable infeed for fixed side: from the bottom
• Bottom housing dimensions: 44 mm wide (excl. mounting loops), 94 mm long, 53 mm high (excl. locking lever)
• Net weight: 0.75 lb
• Made in Germany
